Thermal Broken Aluminum Horizontal Sliding Glass Windows, AS2047 Standard, Interpon Powder Coating, Double Glazed, For Kitchen, Bedroom, Dining Room

Thermal Broken Aluminum Horizontal Sliding Glass Windows, AS2047 Standard, Interpon Powder Coating, Double Glazed, For Kitchen, Bedroom, Dining Room

Thermal Broken Aluminum Horizontal Sliding Glass Windows, AS2047 Standard, Interpon Powder Coating, Double Glazed, For Kitchen, Bedroom, Dining Room
Thermal Broken Aluminum Horizontal Sliding Glass Windows, AS2047 Standard, Interpon Powder Coating, Double Glazed, For Kitchen, Bedroom, Dining RoomThermal Broken Aluminum Horizontal Sliding Glass Windows, AS2047 Standard, Interpon Powder Coating, Double Glazed, For Kitchen, Bedroom, Dining RoomThermal Broken Aluminum Horizontal Sliding Glass Windows, AS2047 Standard, Interpon Powder Coating, Double Glazed, For Kitchen, Bedroom, Dining Room
CategoriesAluminum Sliding Windows
BrandROPO Custom Door and Window Solutions
ModelAluminum Sliding Window 001
Profile ColorWhite / Black / Grey / Customized Color
Profile BrandJMA 6063-T5
HardwareAustralian Doric
GlassSingle / Double / Triple / Laminated / Low E
ScreenFixed / Sliding Screen / Security Screen
FOB portFuzhou / Xiamen
Terms of PaymentL/C, T/T
Update TimeMay 19,2024
Detail Information
Product Introduction
Sliding Window

Sliding windows typically have oversized glass panels that let in plenty of natural light and offer homeowners wide, unobstructed views. They provide plenty of ventilation: Because of their streamlined design, most sliders open fully to let in fresh air.

  •  600Pa

    Water Pressure
  •  3000Pa

    Ultimate Wind Pressure
  • 2.3

    U Value
  • 3.3

    SHGC Value
Australian Standard Aluminum Double Glazed Sliding Window
Product Video

Easy to use:

Unlike traditional double hung windows, sliding windows open horizontally with sashes that slide back and forth rather than up and down, making it a lot easier to operate. This is extremely helpful for seniors or people with limited mobility living inside the house.

Low Maintenance:

Sliding windows are built with fewer parts than other common windows. Remember, pulleys and springs can wear and fail over time. The good thing is, sliding windows do not rely on these components to operate, which makes a lot more durable and easier to maintain in the long run.

Natural Light:

Since sliding windows are mostly made up of expansive glass panels, they bring in lots of natural light and help illuminate the entire living space. This reduces the need for artificial light, helping cut down on utility costs. It also creates a smooth, inviting outdoor flow, perfect for homes surrounded by lush, green trees.

Product PDF
Aluminum Sliding Window Drawing Section
Aluminum Sliding Window Intertek Report
Product Details Map
 Corner Profile :

Multi-chambered frame, JMA Window System (http://www.jma.cn/en/index.php ), 6063-T5, and The Powder Coating is from German Interpon (AkzoNobe Group) (https://www.interpon.com/cn ) for UV resistance. 10 Years Warranty.
Australian Standard Aluminum Double Glazed Sliding Window Corner Profile
Australian Standard Aluminum Double Glazed Sliding Window Details
Details :

1, Silicon Sealant-U.S.A Brand DOW CONING
2, Glass Bead- All glass sealed by glass bead, not silicone. so if the glass is broken, it is easy to change.
3, Rubber strip is EPDM for good sealent and 10 years warranty.
4, All screwn is stainless steel to resist corrosion

Australian Standard Aluminum Double Glazed Sliding Window Hardware
Hardware :
Heavy duty hinge with 304 stainless steel for maximum durability.
Multi-point stainless steel locking device for enhanced security.
Australian Standard Aluminum Double Glazed Sliding Window Configurations
Possible Sliding Window/Fixed (F) Window Configurations :

Aluminum sliding window can be designed with fixed window combined.
One panel sliding window opening width should be limited in 1200mm, the window height is better smaller than 1800mm for maximum using experience and durable.
If the sliding window width bigger than 1200mm, we suggest double panels style or with fixed style.
Glass Should Be Selected On The Basis Of Thermal Insulation Requirement, Sound Insulation Requirement And Safety Requirement.
